Nano Diamond Slurry

20+ Years Experience Consistent Batch Quality Customized Solutions

Product Overview

Nano Diamond Slurry (NDS) is a liquid polishing formulation containing selected nano and submicron diamond abrasives for ultra-fine surface finishing of hard materials. Available in nominal sizes from 30–500 nm, it can be formulated with HPHT-derived or detonation nanodiamond according to the application. Particle sizing, dispersion and carrier selection can be matched to precision polishing requirements for SiC, sapphire, optical crystals and other hard substrates.

Features

Ultra-Fine Diamond Abrasives: Available in nominal sizes from 30–500 nm for fine surface refinement.
Selectable Diamond Types: HPHT-derived or detonation nanodiamond can be selected according to application requirements.
Dispersion Control: Formulation and processing help manage particle distribution and agglomeration.
Fine Material Removal: Supports controlled polishing of selected hard and brittle substrates.
Customizable Formulation: Carrier system, diamond concentration and viscosity can be adjusted as required.

Specifications

Product Type	Nano Diamond Slurry
Product Series	NDS
Abrasive Type	HPHT-Derived Nanodiamond (HND) / Detonation Nanodiamond (DND)
Nominal Particle Size	30–500 nm, depending on the selected grade
Particle Size Specification	Primary particle size and dispersion / aggregate size specified as applicable
Carrier System	Water-Based / Oil-Based, subject to formulation
Diamond Concentration	Customizable; specified in ct/L or wt% according to the supplied formulation
Viscosity and pH	Specified according to the selected formulation and process requirements
Typical Appearance	Dark Gray; may vary with formulation
Packaging	500 mL / 1 L / 5 L / 25 L; custom volumes available upon request
