CBN-P95 – Polycrystalline CBN Grit

20+ Years Experience Consistent Batch Quality Customized Solutions

Product Overview

CBN-P95 is a polycrystalline CBN abrasive grit developed for demanding grinding applications requiring stable grain wear and continuous self-sharpening. Its polycrystalline structure promotes localized micro-fracturing during grinding, progressively exposing fresh cutting edges while reducing the tendency toward sudden large-scale grain breakdown. This controlled wear behavior supports sustained cutting performance in metal-bond and electroplated CBN tools for hardened steels, high-alloy steels and other difficult-to-machine materials.

Features

Polycrystalline CBN Structure: Fine CBN crystallites create a different wear and fracture behavior from conventional monocrystalline CBN.
Controlled Micro-Fracturing: Localized grain breakdown progressively exposes fresh cutting edges during grinding.
Good Self-Sharpening: Continuous abrasive renewal helps maintain active cutting performance.
Stable Grain Wear: Reduces the tendency toward sudden large-scale grain fracture under demanding grinding loads.
Bonded Tool Compatibility: Suitable for metal-bond, electroplated and selected high-performance CBN grinding tools.

Specifications

Abrasive Type	Polycrystalline Cubic Boron Nitride
Product Series	Mesh CBN Grit
Grade	CBN-P95
Color	Grey-Black
Grade Direction	Polycrystalline / Self-Sharpening Grade
Grain Structure	Polycrystalline structure composed of fine CBN crystallites
Typical Morphology	Blocky to irregular polycrystalline grains
Fracture Behavior	Progressive micro-fracturing / self-sharpening
Selection Focus	Stable wear, abrasive renewal and sustained cutting action
Typical Bond Systems	Metal Bond / Electroplated Tools

Comparison Table of Monocrystalline CBN Grit Size

US Mesh Size	GB/T 6406-2016 / ISO 6106	FEPA CBN Designation	Nominal Size Range (μm)
70/80	213	B213	212–180
80/100	181	B181	180–150
100/120	151	B151	150–125
120/140	126	B126	125–106
140/170	107	B107	106–90
170/200	91	B91	90–75
200/230	76	B76	75–63
230/270	64	B64	63–53
270/325	54	B54	53–45
325/400	46	B46	45–38
400/500	39	B39	38–32
500/600	33	B33	32–26

Particle size designations are provided according to commonly used superabrasive grit standards. Product-specific size availability should be confirmed according to the selected CBN grade.
